Technical data
WARNING
Exceeding the maximum overload values (Pmax) can lead to malfunctions and
result in the digital pressure gauge being destroyed.
Overload values
Pressure range
-1...3 bar
-1...5 bar
-1...10 bar
-1...20 bar
-1...40 bar
-1...60 bar
0...100 bar
0...160 bar
0...250 bar
0...400 bar
0...700 bar
0...1000 bar
At 0 bar relative, the following threshold values must be exceeded for a measured value to be
displayed:
Threshold
values
Pressure range
-1...3 bar
-1...5 bar
-1...10 bar
-1...20 bar
-1...40 bar
-1...60 bar
0...100 bar
0...160 bar
0...250 bar
0...400 bar
0...700 bar
0...1000 bar
- 34 -
Overload
12 bar
18 bar
30 bar
50 bar (E2)
48 bar (D2 / C2)
80 bar
120 bar
200 bar
320 bar
500 bar
800 bar
1200 bar
1500 bar
Type E2
Threshold value
[bar]
0.006
0.010
0.020
0.04
0.08
0.12
0.20
0.32
0.5
0.8
1.4
2.0
Resolution Threshold value
[bar]
0.002
0.002
0.003
0.01
0.01
0.02
0.03
0.04
0.1
0.1
0.2
0.3
© SIKA • Ba_Ref-E2D2C2 • 07/2021
E2 / D2 / C2
Burst pressure
20 bar
30 bar
50 bar
250 bar (E2)
80 bar (D2 / C2)
400 bar
550 bar
800 bar
1000 bar
1200 bar
1700 bar
2400 bar
2500 bar
Type D2 / C2
Resolution
[bar] [bar]
0.003 0.002
0.005 0.002
0.01 0.003
0.02 0.01
0.04 0.01
0.06 0.02
0.1 0.03
0.16 0.04
0.3 0.1
0.4 0.1
0.7 0.2
0.5 0.3
