6. Protective Functions

Seizing Protection

If the anti-seizing protection is activated, the controller will switch the heat pump and the mixer on/off for 5 seconds at 12:00 noon
to prevent seizing of the pump/valve after long periods of inactivity.

Frost Protection

If the outdoor temperature on sensor S1 measures less than 1 °C and the heating circuit is turned off, the heating circuit will auto-
matically be turned on, if frost protection is activated and the reference flow temperature is set at the minimum flow temperature;
setting under 'Min. Flow' on page 1. As soon as the outdoor temperature exceeds 1 ° C, the frost protection is switched off again.
Switching the frost protection function off or setting the minimum flow temperature too low can lead to severe damage
to the system.

7. Special Functions

Program Selection

Here, the appropriate hydraulic variant for the respective use case is selected and set.
The program is normally selected by a specialist only once during first entry into service. Incorrect program selection
may lead to unpredictable errors.

Pump Settings

In this menu, settings can be made to the 0-10 V or the PWM pump.
If this menu is selected, you may receive a request to save the speed settings.
Signal type
The type of device to be controlled is set here.
0-10 V: Controlled by a 0-10 V signal.
PWM: Controlled by a PWM signal.
Pump
In this menu, the preset profiles for the pump can be selected or under 'manual' all settings can be made manually. The settings
can still be changed after a profile has been selected.
'Protective functions' can be used by specialists to activate and set various
protective functions.
The controller must never replace the safety appliances on site!
These are used to set basic items and expanded functions.
The settings in this menu should only be changed by a specialist.
