5.2 Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
, , ... Series of steps
1. 2. 3.
6

Tools list

7

Replacement of transmitter

7.1 Backing up the data
Remove the T-DAT currently in the old transmitter and insert the T-DAT into the new
transmitter.
7.2 Removing the transmitter
The S-DAT remains in the sensor interface.
WARNING
L
The measuring device is energized!
Risk of fatal injury from electric shock.
‣
Open the measuring device only when the device is de-energized.
Endress+Hauser
3 mm, 4 mm
0.5 x3.5 mm
T20
EA01263D
7
