EA01263D
14 →
3.
‣
Removal of transmitter version for hazardous areas: turn the transmitter
and lift it up.
7.3 Mounting the replacement transmitter
Before installing the replacement transmitter, remove the cover, the electronics etc. as
described in Section 7.2 "Removing the transmitter" .
Reassemble the replacement transmitter in the reverse order as described in Section 7.2
→  7.
Note the following:
1 →
1.
‣
To reassemble the transmitter version for non-hazardous areas: turn the
transmitter as far as it will go and then turn it back as far as the securing
screw.
10
2.
1.
3.
7 Nm (5.2 lbf ft)
2.
4 mm
4 mm
15
2.
0,6 Nm
(0.4 lbf ft)
Endress+Hauser
1.
T10
