Tools List; Replacing The Sensor - Endress+Hauser Prosonic Flow G 300-digital Installationsanleitung

6

Tools list

Box wrench
22 mm
26 mm
7

Replacing the sensor

7.1 Removing the sensor and replacing the O-ring for the cover of
the cable duct
DANGER
L
Risk of injury!
‣
To replace the sensor, the pipe must be completely free from pressure. Residual pressure
on the pipe can cause the sensor to pop out suddenly as soon as the sensor is released!
‣
In the case of toxic, explosive or flammable fluids, the pipe in which the measuring device
is installed must be rinsed or cleaned before the sensor is replaced!
‣
Before starting work, allow the pipe to cool down to a safe temperature.
When removing/installing the same sensor, the external sensor seals must be replaced.
1 →
2.
Endress+Hauser
Hexagon wrench
Hexagon nut
26 mm
Torque wrench
19 mm
32 mm
1.
2 →
EA01254D
