stallation site for concealed electrical cables, gas and
water pipes using a pipe locator.

Operation

Use only proper equipment.
• Do not force the machine or accessory not to do the
work of a larger industrial machine. It works better at
the power rating for which it was designed.
• Make all machine adjustments only with the machine
switched off.
• Never leave the machine unattended while it is run-
ning.
• When switching off, leave the machine only after it
comes to a complete standstill.
• Turn the machine off before you unplug it.
• Always unplug the mains cord. Never pull out the
plug from the wall outlet by holding the cable.
• Perform maintenance and cleaning of the device re-
gularly.
• Have the device checked, if necessary.
If you are not sure whether a working condition is safe or
unsafe, do not work with the machine.
FEATURES FIG.1
1 Motor housing
2 Handle
3 On / Off switch
4 Additional handle
5 Tool holder
6 Locking bolt
7 Oil fill opening / sight glass
8 Point chisel

Getting started

Using the chisel Fig. 2
1 Clean chisel always before inserting it and lubricate
the shaft slightly.
2 Pull out the locking bolts (6) up to the end stop,
turn by 180° and release.
3 Insert chisel into the tool holder (5) and slide it up
to the end stop.
4 Pull out the locking bolts (6) once again, turn by
180° and release.
5 Check lock on the tool.
Remove chisel
Pull out the locking bolts (6) up to the end stop, turn by
180° and release, and remove the chisel.
Additional handle Fig.3
For safety reasons, use the demolition hammer only with the
additional handle!
17
