Block lock Activation slave

6 Installing the activation slave

EN
Mount the activation slave above the door frame. Keep
a distance of at least one and a half metres from other
SimonsVoss components (see drawing) to prevent
mutual interference.
Align the activation unit so that the fastening screws
are in a horizontal line (see drawing) in order to rule
out interference during normal door operation.
Deactivation
unit
No separate antenna is used for this installation.
Therefore, plug jumper B2 to maximise the range (see
manual).
6. Installing the activation slave
≥150 cm
Locking cylinder
Activation unit
25 / 108
