Levelflex M FMP41C, FMP45
Endress+Hauser
Bestellinformationen Levelflex M FMP45
10 Zulassung:
A Ex-freier Bereich
F Ex-freier Bereich, WHG
1 ATEX II 1/2G Ex ia IIC T6/IECEx Zone 0/1
2 ATEX II 1/2D / IEC Ex td A20/21, Alu Blinddeckel
3 ATEX II 1/2G Ex emb (ia) IIC T6/IECEx Zone 0/1
4 ATEX II 1/3D / IEC Ex td A20/22
5 ATEX II 1/2G Ex ia IIC T6, ATEX II 1/3D
6 ATEX II 1/2G Ex ia IIC T6, WHG
7 ATEX II 1/2G Ex d (ia) IIC T6 / IEC Ex d(ia) IIC T6
8 ATEX II 1/2G Ex ia IIC T6, ATEX II 1/3D, WHG
G ATEX II 3G Ex nA II T6
H ATEX II 3G ic IIC T6 Gc
C NEPSI Ex emb (ia) IIC T6
I NEPSI Ex ia IIC T6
J NEPSI Ex d(ia) IIC T6
Q NEPSI DIP (In Vorbereitung)
R NEPSI Ex nA II T6
M FM DIP Cl.II Div.1 Gr. E-G N.I.
S FM IS Cl.I,II,III Div.1 Gr. A-G N.I., Zone 0, 1, 2
T FM XP Cl.I,II,III Div.1 Gr. A-G, Zone 1, 2
N CSA General Purpose
P CSA DIP Cl.II Div.1 Gr. G + coal dust, N.I.
U CSA IS Cl.I,II,III Div.1 Gr. A-D, G+coal dust, N.I., Zone 0, 1, 2
V CSA XP Cl.I,II,III Div.1 Gr. A-D, G+coal dust, N.I., Zone 1, 2
K TIIS Ex d (ia) IIC T1
L TIIS Ex d (ia) IIC T2
Y Sonderausführung, TSP-Nr. zu spez.
20 Prozesstemperatur:
A -200...+280 °C (XT); Sattdampfanwendungen max. 200 °C
B -200...+400 °C (HT)
Y Sonderausführung, TSP-Nr. zu spez.
30 Sonde:
A ..... mm, Seil 4mm, 316
C ..... inch, Seil 1/6", 316
K ..... mm, Stab 16 mm, 316L
L ..... mm, Koax, 316L
M ..... inch, Stab 16 mm, 316L
N ..... inch, Koax, 316L
S ..... mm, Stab 16 mm, 316L, 500 mm teilbar
T ..... mm, Stab 16 mm, 316L, 1000 mm teilbar
U ..... inch, Stab 16 mm, 316L, 20 in teilbar
V ..... inch, Stab 16 mm, 316L, 40 in teilbar
Y Sonderausführung, TSP-Nr. zu spez.
40 Prozessanschluss:
AFJ 2" 150lbs RF, 316/316L Flansch ANSI B16.5
AGJ 3" 150lbs RF, 316/316L Flansch ANSI B16.5
AHJ 4" 150lbs RF, 316/316L Flansch ANSI B16.5
ARJ 2" 300/600lbs RF, 316/316L Flansch ANSI B16.5
ASJ 3" 300/600lbs RF, 316/316L Flansch ANSI B16.5
ATJ 4" 300lbs RF, 316/316L Flansch ANSI B16.5
A1J 2" 1500lbs RF, 316/316L Flansch ANSI B16.5
A2J 3" 1500lbs RF, 316/316L Flansch ANSI B16.5
A3J 4" 600lbs RF, 316/316L Flansch ANSI B16.5
A4J 4" 900lbs RF, 316/316L Flansch ANSI B16.5
A5J 4" 1500lbs RF, 316/316L Flansch ANSI B16.5
CHJ DN100 PN10/16 B1, 316L Flansch EN1092-1 (DIN2527 C)
CRJ DN50 PN10-40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CSJ DN80 PN10-40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CTJ DN100 PN25/40 B1, 316L Flansch EN1092-1 (DIN2527 C)
C1J DN50 PN63 B2, 316L Flansch EN1092-1 (DIN2527 E)
C2J DN50 PN100 B2, 316L Flansch EN1092-1 (DIN2527 E)
C3J DN80 PN63 B2, 316L Flansch EN1092-1 (DIN2527 E)
C4J DN80 PN100 B2, 316L Flansch EN1092-1 (DIN2527 E)
C5J DN100 PN63 B2, 316L Flansch EN1092-1 (DIN2527 E)
