Introduction

You have chosen our CONCORD trimax seat for the
protection of your child.
This product is manufactured using rigorous quality
control procedures, but its exceptional safety features
will only work if you use it correctly. It is therefore
important to follow carefully the instructions for fitting
and using the seat. This seat can be used on any car seat
fitted with a three-point safety belt, but accident statistics
suggest that the best place is on the seat behind the front
passenger's seat.
The seat basically comprises three parts: the backrest with
three-position adjustable shoulder straps, the removable
IMAGE 3 booster seat, and the sit/recline adjustment
section.
Use of Image 3 to raise seat:
For optimum safety, we urgently recommend using the
seat Image 3 in conjunction with the easily retrofitted
CONCORD Lift Pro backrest.
Securing the seat in the car using a three-point
safety belt
Fig. 1
Position the TRIMAX on the seat of the car. Pull the car
safety belt right out and thread its clip through the slot
in the backrest.
Fig. 2,3 Secure the three-point safety belt just as you would on
a grown-up, while ensuring that the belts pass through
the guides.
Fig. 3
Slide the diagonal belt into the belt grip situated at the top
of the slot in the backrest. Press the seat firmly into the car' s
seat cushioning while pulling tight the diagonal belt; this
should also pull the waist belt tight. The belt grip ensures
that the seat stays firmly in position. Look to make sure
that the safety belt is not twisted and is tight in every place.
