You can check that the safety belt is properly in place by
lifting the backrest cover. Tighten the belt if necessary.

Securing your child

Should you wish to lengthen the belts, release the harness
buckle and lift the central adjuster at the front of the seat
and pull the shoulder harnesses forwards.
Pull the two buckle latches off the seat and the buckle
forwards. Sit your child in the seat. Place the two buckle
latches together and then connect the visible metal part to
the buckle. Lock the system by tipping it forwards slightly.
An audible click will be heard.
Check that the belts are not twisted.
Only if the harness straps are positioned correctly and
securely will your child have optimum protection. Therefore
the belt length should be correct when your child wears
different clothing. Tighten the sytem by pulling the belt on
the central adjuster.
The pelvis belts pad should be located to ensure that it
covers the route of the pelvis belts, make sure the harness
is fi rmly adjusted.
Ensure that the cover does not become jammed beneath
the adjustment button so that the blocking function is not
impaired. To remove the child release the belt system by
pushing the red buttom.
Trimax belt and buckle padding
The car seat Trimax is supplied with a harness system
fi xed on the back rest.
When the child is secured with the 5-point central
harness the belt and buckle pads have to be correctly
adjusted to the child.
