AMCO VEBA 808N Anweisungs- Bedienungs Und Wartungshandbuch Seite 179

SCHEMA ELETTRICO
CABLAGGI
RADIOCOMANDI
HETRONIC-SCANRECO
[5.16.0006]
ELECTRIC DIAGRAM
RADIO REMOTE CONTROLS
WIRINGS
HETRONIC-SCANRECO
[5.16.0006]
1 1
2
3
4
5
6
7
8
9
10
4
11
3
12
2
1
XS8
XS8
908N
BMS2-HETRONIC
1
2
Marrone brown (1)
3
Giallo yellow (2)
4
Verde green (3)
5
Blu blue (4)(g/v)
6
7
8
9
10
SCANRECO
1
2
Marrone brown (1)
3
Giallo yellow (2)
4
Verde green (3)
5
Blu blue (4)(g/v)
6
7
8
D-40
STROMKREISSCHEMA
FUNKFERNSTEUERUNG -
VERDRAHTUNGEN
HETRONIC-SCANRECO
[5.16.0006]
Reset =START Brown (1)
Black (2)
AVPS
PLE white (1 turtle)
Valve power 2= CAVO + EV
Rpm + Orange (2)
Blue (3)
Rpm -
Motor Start Violet (4)
Gray (5)
Motor Stop
OPTION (6)
EARTH (Yellow-green)
Reset (n.7 SCANRECO EX)
AVPS (n.6 SCANRECO EX2)
PLE 80% (n.5 SCANRECO EX2)
Valve power (POWER CABLE DV)
Rpm + (n.4 SCANRECO EX)
(n.5 SCANRECO EX)
Rpm -
Motor Start (n.2 SCANRECO EX)
Motor Stop (n.8 SCANRECO EX)
