1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
NOTE:
In accordance with the applicable product li-
ability laws, the manufacturer of this device as-
sumes no liability for damage to the device or
caused by the device arising from:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord-
ance with the recommendations.
The operating instructions contain important infor-
mation on how to operate the machine safely, pro-
fessionally and economically, how to avoid danger,
costly repairs, reduce downtimes and how to in-
crease reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula-
tions that apply for the operation of the machine in
your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information. The machine can only
be operated by persons who were instructed con-
cerning the operation of the machine and who are in-
formed about the associated dangers. The minimum
age requirement must be complied with.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
In addition to the safety notices contained in this
operating manual and the particular instructions for
your country, the generally recognised technical reg-
ulations for the operation of identical devices must
be complied with.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
2. Device description (fig. 1-2)
1. Machine foot
2. Column
3. Clamping handle
4. Drilling table
5. Motor
6. Speed adjustment lever (handle)
7. V-belt cover
8. Digital display
9. On and off switch
10. Handle
11. Folding swarf protector
12. Drill chuck (illustration may differ)
13. Machine head
14. On and off switch laser
15. Depth indicator with stop
16. Crank handle
17. Hexagonal screw
A. Allen wrench 4 mm
B. Allen wrench 3 mm
C. Battery

3. Scope of delivery

• Machine foot 1x
• Column 1x
• Clamping handle 1x
• Drilling table 1x
• Speed adjustment lever (handle) 1x
• Handle 3x
• Folding swarf protector 1x
• Drill chuck 1x
• Machine head 1x
• Crank handle 1x
• Hexagonal screw 4x
• Battery 2x
• Allen wrench 2x
