1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
we hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 570,813 /
VDE0113.
We recommend:
Read through the complete text in the operating instruc-
tions before installing and commissioning the device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord-
ance with the recommendations.
The operating instructions contain important informa-
tion on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, cost-
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regu-
lations that apply for the operation of the machine in
your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information.
The machine can only be operated by persons who were
instructed concerning the operation of the machine and
who are informed about the associated dangers. The
minimum age requirement must be complied with.
In addition to the safety instructions contained in this
operating manual and the specific regulations of your
country, the technical rules generally accepted for the
operation of machines of the same type must be ob-
served.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.

2. Device description

1. Base plate
2. Pillar
3. Drilling table
4. Machine head
5. Drill chuck
6. Grips
7. Drill chuck protection
8. Depth stop
9. Motor
10. On-Off switch
11. Belt protective hood
12. Counternuts for belt tension
13. Laser module
13.1 Laser on/off switch
13.2 Battery compartment cover
14. Vice
A Hexagonal screw
B 4 mm Allen key
C Vice fastening screws
D Drill chuck key
E Table locking
F Allen screws
G Nut fastening, depth stop
H Philips screw, chuck guard
I Hole housing, depth stop
J Nut, depth stop
K Pointer, depth stop
L Groove
M Spring cap
N Inner nut
O Outer nut
P Hub
S Table locking
T Laser set screw
U Laser countersunk screw
V Belt guard screw
W Laser locknut

3. Scope of delivery

• Base plate
• Pillar
• Drilling table
• Machine head
• Drill chuck
• Drill chuck key
