ISOMETER® isoMIL425
i
Bestandteil der Gerätedokumentation sind neben
dieser
Kurzanleitung
„Sicherheitshinweise für Bender-Produkte" und
das Handbuch, herunterladbar unter https://
www.bender.de/service-support/downloadbe-
reich. Die Kurzanleitung ersetzt nicht das
Handbuch.
Lieferumfang
• ISOMETER® isoMIL425HV
• Ankoppelgerät AGH421-W
• Montageclip
• Sicherheitshinweise für Bender-Produkte
• Kurzanleitung DE/EN
Bestellangaben
Typ/Type
isoMIL425HV-D4W-4
AC 0...690 V
mit/with AGH421-W
DC 0...1000 V, 15...460 Hz
Montageclip für Schraubmontage (1 Stück je Gerät)
Mounting clip for screw fixing (1 piece/device)
Bestimmungsgemäße Verwendung
Das ISOMETER® der Serie isoMIL425HV überwacht den
Isolationswiderstand R
Hauptstromkreisen
Netznennspannungen von 3(N)AC, AC/DC 0 ... 690 V
oder DC 0 ... 1000 V. Die in 3(N)AC, AC/DC-Systemen
vorhandenen gleichstromgespeisten Komponenten ha-
ben keinen Einfluss auf das Ansprechverhalten, wenn
mindestens ein Laststrom von DC 10 mA fließt. Durch
die separate Versorgungsspannung U
Überwachung eines spannungslosen Systems möglich.
Die maximal zulässige Netzableitkapazität C
700 μF. Das ISOMETER® wird stets mit dem
Ankoppelgerät AGH421 betrieben werden.
Eine andere oder darüber hinausgehende Benutzung
gilt als nicht bestimmungsgemäß.
i
Zwischen L1/+ und L2/- muss für die korrekte
Funktion
Netzinnenwiderstand ≤ 1 kΩ über die Quelle (z. B.
Transformator) oder die Last vorhanden sein.
2
isoMIL425HV_D00204_05_Q_DEEN / 02.2021
die
beiliegenden
Nennspannung /
Nominal voltage U
n
AC 100...240 V, 47...63 Hz
DC 24...240 V
von ungeerdeten AC/DC-
F
(IT-Systemen)
ist auch die
s
des
ISOMETER®s
ISOMETER® isoMIL425
i
Part of the device documentation in addition to
this quickstart is the enclosed "Safety instructions
for Bender products" and the manual, which can
be downloaded from https://www.bender.de/en/
service-support/downloads.The quickstart does
not replace the manual.
Scope of delivery
• ISOMETER® isoMIL425HV
• Coupling device AGH421-W
• Mounting clip
• Safety instructions for Bender products
• Quickstart DE/EN
Ordering information
Versorgungsspannung /
Supply voltage U
s
Intended use
The ISOMETER® of the isoMIL425HV series monitors the
insulation resistance R
mit
cuits (IT systems) with nominal system voltages of
3(N)AC, AC/DC 0 ... 690 V or DC 0 ...1000 V. DC compo-
nents existing in 3(N)AC, AC/DC systems do not influen-
ce the operating characteristics, when a minimum load
current of DC 10 mA flows. A separate supply voltage U
allows de-energised systems to be monitored too. The
maximum permissible system leakage capacitance C
700 μF. The ISOMETER® is always used in conjunction
beträgt
with the coupling device AGH421.
e
Any use other than that described in this quickstart is
regarded as improper.
i
To ensure that the ISOMETER® functions correctly,
ein
an internal resistance of ≤1 kΩ must exist bet-
ween L1/+ and L2/- via the source (e.g. the trans-
former) or the load.
Handbuch Nr. /
Art.-Nr. / Art. No.
Manual No.
B71036305W
D00204
B98060008
of unearthed AC/DC main cir-
F
s
is
e
