Bender ISOMETER isoCHA425HV Kurzanleitung
Bender ISOMETER isoCHA425HV Kurzanleitung

Bender ISOMETER isoCHA425HV Kurzanleitung

Isolationsüberwachungsgerät mit ankoppelgerät für ungeerdete dc-systeme (it-systeme) dc 0 v bis 1000 v
Vorschau ausblenden Andere Handbücher für ISOMETER isoCHA425HV:

Werbung

ISOMETER® isoCHA425HV & AGH420-1
Isolationsüberwachungsgerät mit Ankoppelgerät für ungeerdete
DC-Systeme (IT-Systeme) DC 0 V bis 1000 V
Insulation monitoring device with coupling device for unearthed
DC systems (IT systems) DC 0 V up to 1000 V
isoCHA425HV_D00404_02_Q_DEEN/ 11.2021
Kurzanleitung/Quickstart DE/EN

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Bender ISOMETER isoCHA425HV

  • Seite 1 ISOMETER® isoCHA425HV & AGH420-1 Isolationsüberwachungsgerät mit Ankoppelgerät für ungeerdete DC-Systeme (IT-Systeme) DC 0 V bis 1000 V Insulation monitoring device with coupling device for unearthed DC systems (IT systems) DC 0 V up to 1000 V isoCHA425HV_D00404_02_Q_DEEN/ 11.2021 Kurzanleitung/Quickstart DE/EN...
  • Seite 2 Part of the device documentation in addition to dieser Kurzanleitung „Sicher- this quickstart is the enclosed “Safety instructi- heitshinweise für Bender-Produkte“ und das ons for Bender products“ and the manual, dazugehörige Handbuch, herunterladbar unter which can be downloaded from https://www. https://www.bender.de/service-support/down- bender.de/en/service-support/downloads. loadbereich.
  • Seite 3 ISOMETER® isoCHA425HV & AGH420-1 Merkmale CHAdeMO Mode "CHd" und "CHA" Features CHAdeMO mode "CHd" and CHA" Mode CHAdeMO Maximale Netzableitkapazität 1,6 µF je Leiter Maximum system leakage capacitance 1.6 μF per   conductor Erkennung von Isolationsfehlern im Netzspannungsbereich Detection of insulation faults in the system voltage ...
  • Seite 4: Montage

    ISOMETER® isoCHA425HV & AGH420-1 Montage Mounting Click & Click! Variante A / Option A: Variante B / Option B: Montage auf Hutschiene / DIN rail mounting Schraubbefestigung / Screw mounting Anschlussbild Wiring diagram DC + DC - Test / Reset GND AK2 >...
  • Seite 5: Legende Zum Anschlussbild

    ISOMETER® isoCHA425HV & AGH420-1 Legende zum Anschlussbild Wiring diagram legend Klemme/ Anschlüsse Connections Terminal A1, A2 Anschluss an die Versorgungsspannung U über Connection to the supply voltage U via a fuse: Schmelzsicherung: If supplied from an IT system, both lines have to be protected by a Bei Versorgung aus IT-System beide Leitungen absichern.* fuse.* E, E, KE...
  • Seite 6: Menü-Übersicht

    ISOMETER® isoCHA425HV & AGH420-1 Menü-Übersicht Menu overview Messwertanzeige Menüauswahl Parametereingabe Measurement display Menu selection Parameter selection > < 1.5 s > > . . . 1.5 s 1.5 s < t > 5 Min. < > 1.5 s R [k ] C [µF] U L1 L2 [V ] UL1 [V ]...
  • Seite 7: Display Elements

    ISOMETER® isoCHA425HV & AGH420-1 Display-Elemente Display elements Funktion Gerätefront/ Device front Function grün - On green - On gelb - Alarm yellow - Alarm gelb - Alarm yellow - Alarm Aufwärts-Taste Up button Test-Taste (> 1,5 s drücken) Test button (press > 1.5 s) Bei gedrückter Test-Taste werden die By pressing and holding the test Display-Elemente angezeigt.
  • Seite 8: Technische Daten

    ISOMETER® isoCHA425HV & AGH420-1 Technische Daten Technical data Isolationskoordination nach IEC 60664-1/IEC 60664-3 Insulation coordination acc. to IEC 60664-1/IEC 60664-3 Bemessungsspannung ..............240 V Rated voltage ................240 V Überspannungskategorie ..............III Overvoltage category ..............III Versorgungsspannung Supply voltage Versorgungsspannung U ....AC 100…240 V/ DC 24…240 V Supply voltage U .
  • Seite 9 ISOMETER® isoCHA425HV & AGH420-1 Mode CHAdeMO (CHd und CHA) Mode CHAdeMO (CHd and CHA) Netzspannung U ................System voltage U ............................. Messbetrieb erst ab U .......... Measuring mode only from U ≥ 50 V ≥ 50 V Zulässige Netzableitkapazität C ......je Leiter ≤...
  • Seite 10: Technische Daten Agh420

    ISOMETER® isoCHA425HV & AGH420-1 Federklemmen: Push-wire terminals: Nennstrom ................≤ 10 A Nominal current ..............≤ 10 A Querschnitt ..............AWG 24…14 Cross section ..............AWG 24…14 Abisolierlänge .................10 mm Stripping lenght ..............10 mm Starr ................0,2…2,5 mm Rigid ................0.2…2.5 mm Flexibel ohne Aderendhülse.
  • Seite 11 ISOMETER® isoCHA425HV & AGH420-1 isoCHA425HV_D00404_02_Q_DEEN/ 11.2021...
  • Seite 12 Nachdruck und Vervielfältigung Reprinting and duplicating nur mit Genehmigung des Herausgebers. only with permission of the publisher. Bender GmbH & Co. KG Bender GmbH & Co. KG Postfach 1161 • 35301 Grünberg • Deutschland PO Box 1161 • 35301 Grünberg • Germany Londorfer Str.
