Umwelt/EMV
EMV .................................................... IEC 61326-2-4, DIN EN50121-3-2
Umgebungstemperaturen:
Betrieb .............................................................................. -40...+70 ºC
Transport .......................................................................... -50...+85 ºC
Lagerung........................................................................... -55...+80 ºC
Klimaklassen nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) .................................................. 3K24
Transport (IEC 60721-3-2) .............................................................. 2K11
Langzeitlagerung (IEC 60721-3-1) .................................................. 1K23
Mechanische Beanspruchung nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) ................................................. 3M12
Transport (IEC 60721-3-2) ............................................................... 2M4
Langzeitlagerung (IEC 60721-3-1) ................................................. 1M12
Anschluss
Anschlussart ...................................................................... Federklemme
Nennstrom ................................................................................... ≤ 10 A
Querschnitt ...........................................................................AWG 24-14
Abisolierlänge ..............................................................................10 mm
starr .................................................................................0,2...2,5 mm²
flexibel ohne Aderendhülse ...........................................0,75...2,5 mm²
flexibel mit Aderendhülse mit/ohne Kunststoffhülse ....0,25...2,5 mm²
Mehrleiter flexibel mit TWIN Aderendhülse mit Kunststoffhülse .......
.........................................................................................0,5...1,5 mm²
Öffnungskraft ...................................................................................50 N
Testöffnung, Durchmesser ..........................................................2,1 mm
Verdrahtung der Klemmen Up, AK1, GND, AK2 ..................................
..................................siehe technische Daten AGH421, Rubrik Anschluss
Sonstiges
Betriebsart ......................................................................... Dauerbetrieb
Einbaulage .............. Kühlschlitze müssen senkrecht durchlüftet werden
Schutzart Einbauten (DIN EN 60529) ............................................... IP30
Schutzart Klemmen (DIN EN 60529) ................................................ IP20
()* = Werkseinstellung
Technische Daten AGH421
Isolationskoordination nach IEC 60664-1/IEC 60664-3
Bemessungsspannung ................................................................. 1000 V
Überspannungskategorie ..................................................................... III
Verschmutzungsgrad ............................................................................ 3
Überwachtes IT-System
Netznennspannungsbereich U
Toleranz von U ................................................................. AC/DC +10 %
n
10 isoMIL425HV_D00204_05_Q_DEEN / 02.2021
.................................. AC/DC 0...1000 V
n
Environment/EMC
EMC ..................................................... IEC 61326-2-4, DIN EN50121-3-2
Ambient temperatures:
Operation .......................................................................... -40...+70 ºC
Transport .......................................................................... -50...+85 ºC
Storage ............................................................................. -55...+80 ºC
Climatic class acc. to IEC 60721:
Stationary use (IEC 60721-3-3) ....................................................... 3K24
Transport (IEC 60721-3-2) .............................................................. 2K11
Long-time storage (IEC 60721-3-1) ................................................ 1K23
Classification of mechanical conditions acc. to IEC 60721:
Stationary use (IEC 60721-3-3) ...................................................... 3M12
Transport (IEC 60721-3-2) ............................................................... 2M4
Long-term storage (IEC 60721-3-1) ............................................... 1M12
Connection
Connection type ........................................................push-wire terminal
Nominal current ........................................................................... ≤ 10 A
Cross section .........................................................................AWG 24-14
Stripping length ...........................................................................10 mm
rigid .................................................................................0.2...2.5 mm²
flexible without ferrules.................................................0.75...2.5 mm²
flexible with ferrules with/without plastic sleeve ..........0.25...2.5 mm²
Multi-conductor flexible with TWIN ferrules with plastic sleeve ........
.........................................................................................0.5...1.5 mm²
Opening force ..................................................................................50 N
Test opening, diameter ...............................................................2.1 mm
Wiring of the terminals Up, AK1, GND, AK2 .......................................
........... refer to technical data AGH421 under the heading "Connection"
Other
Operating mode .................................................... continuous operation
Mounting .............................. cooling slots must be ventilated vertically
Degree of protection, built-in components (DIN EN 60529) ............. IP30
Degree of protection, terminals (DIN EN 60529) .............................. IP20
()* = factory setting
Technical data AGH421
Insulation coordination acc. to IEC 60664-1/IEC 60664-3
Rated voltage ............................................................................... 1000 V
Overvoltage category ........................................................................... III
Pollution degree ................................................................................... 3
Monitored IT system
Nominal system voltage range U
Tolerance of U .................................................................. AC/DC +10 %
n
.............................. AC/DC 0...1000 V
n
