Tab. 16
Status
POWER_ON
WAIT_PRM
WAIT_CFG
DATA_EX
Figure 48
Tab. 17
Status
POWER_ON
SRC_ADDR
IDENTIFY
DATA_EX
Turbo-V 81-AG Rack Controller User Manual / 87-900-986-01
Profibus State Machine
Meaning
Interface set-up
Wait for parameterisation from the master
Wait for configuration from the master
Regular data exchange

Profibus State Machine

Meaning
Interface set-up
Search for the controller serial address
Identify controller model and protocol

Regular data exchange

Technical Information
Profibus Option
(I)
17
