17 Technical Information
Controller Connection
Tab. 5
PIN N.
1
2
3
4
5
6
7
8
9

Connector Examples

Figure 27
228/306
SIGNAL NAME
+5 V (OUT) (Reserved)
TX (RS232
RX (RS232
NC
GND
A + (RS485)
NC
B – (RS485)
RESERVED
5
2
PC
3
RS – 232 Connection
Turbo-V 81-AG Rack Controller User Manual / 87-900-986-01
5
TV 301 AG
2
Rack Controller
3
(I)
