17 Technical Information
Controller Connection

Programmable Analog Output Diagrams

Output Voltage
Figure 19
Output Voltage
Figure 20
224/306
V (Volt)
10
0
Programmable analog output related to frequency
V (Volt)
10
0
Programmable analog output related to power
Turbo-V 81-AG Rack Controller User Manual / 87-900-986-01
1350
Frequency (Hz)
150
Power (W)
(I)
