How to Use by Front Panel

Figure 31
Start Stop and Reset Fail button
1
2
The front panel START/STOP function is available only if the controller is set to
NOTE
"FRONT mode". If it is set to "REMOTE mode", when the key is pressed an error
message is shown indicating "COMMAND LOCKED IN REMOTE", if it is set to
"SERIAL" mode, the "COMMAND LOCKED IN SERIAL MODE" error message is
displayed.
The "Reset Fail" function is always available regardless of controller mode.
Turbo-V 81-AG Rack Controller User Manual / 87-900-986-01
LS
AG
COUNTERS
increase
decrease
LOW SPEED
Press once for the START command and again for the STOP
command.
In the case of controller's failure, press once to reset the fail
condition.
Technical Information
How to Use by Front Panel
VACUUM TECHNOLOGIES
MEASURES
menu
START/STOP
Turbo-V 81-AG
(I)
R1
R2
next
previous
