CHANGE THE SPARK PLUG
Remove the Snow Hood
1. Remove the choke control knob (A A , Figure 27).
2. Remove the safety key (B B ).
3. Remove the mounting screws (A A , Figure 28).
4. Slowly remove the snow hood (B B ) Make sure that the primer button
hose (C C ) and the ignition wire (D D ) are not disconnected.
5. The spark plug (E E ) can now be accessed.
6. To install the snow hood, first make sure that the primer button hose
and the ignition wire are connected.
7. Mount the snow hood to the engine and secure with the mounting
screws.
8. Connect the choke control knob (A A , Figure 29) with the choke shaft
on the carburetor (B B ). Make sure the choke control knob is properly
installed. If the choke control knob is not installed correctly, the
choke will not operate.
9. Install the safety key (C C ).
Check and Replace Spark Plug
Check the spark plug every twenty-five (25) hours. Replace the spark plug
(Figure 30) if the electrodes are pitted or burned or if the porcelain is
cracked.
1. Remove snow hood (see "Remove the Snow Hood" section).
2. Clean spark plug and reset gap periodically.
3. Clean area around spark plug base before removal, to prevent dirt
from entering engine.
4. Replace spark plug if electrodes are pitted or burned or if porcelain is
cracked.
5. Clean spark plug by carefully scraping electrodes (do not sandblast
or use wire brush).
6. Be sure spark plug is clean and free of foreign material. Check
electrodes gap with a wire feeler gauge and reset gap to 0.030"
(0.76 mm) if necessary.
7. Before installing spark plug, coat threads lightly with graphite grease
to insure easy removal.
8. Tighten plug firmly into engine. If torque wrench is available, tighten
plug to 18-23 ft-lbs (24.4-31.2 Nm).
WARNING: Always turn unit off, remove ignition key,
and disconnect the spark plug wire before making any
repairs or adjustments.
ADJUST SKID HEIGHT
This snow thrower is equipped with two height adjust skids, secured to
the outside of the auger housing. These elevate the front of the snow
thrower.
When removing snow from a hard surface area such as a paved driveway
or walk, adjust the skids up to bring the front of the snow thrower down.
When removing snow from rock or uneven construction, raise the front of
the snow thrower by moving the skids down. This will help to prevent
rocks and other debris from being picked up and thrown by the augers.
To adjust skids, proceed as follows:
1. Place a block (equal to height from ground desired) under scraper
bar near but not under skid.
2. Loosen skid mounting nuts (A A , Figure 31) and push the skid down
(B B ) until it touches the ground. Retighten mounting nuts.
3. Set skid on other side at same height.
NOTE: Make sure that snow thrower is set at same height on
both sides.
WARNING: Be certain to maintain proper ground
clearance for your particular area to be cleared.
Objects such as gravel, rocks, or other debris, if
struck by the impeller, may be thrown with sufficient
force to cause personal injury, property damage, or
damage to the snow thrower.
MAINTENANCE
