Snow Thrower Controls
SNOW THROWER CONTROLS
A. Speed Select Lever — Allows the operator to use one of six (6)
forward and two (2) reverse speeds (see Figure 10). To shift, move
speed select lever to desired position.
NOTICE: Do not move speed select lever while Traction
Drive Clutch is engaged. This may result in severe damage
to drive system.
B. Auger Control Lever — Used to engage and disengage the auger
and impeller. To engage push down, to disengage release.
C. Chute Rotation Crank — Used to rotate the discharge chute to the
left or right.
C
F
SNOW THROWER AND ENGINE CONTROLS
D. Chute Deflector Wing Nut — Used to control the angle of the
E. Traction Control Lever — Used to propel snow thrower forward or
F. Skid Shoe — Used to adjust ground clearance of auger housing.
G. Clean-Out Tool — Used to remove snow and debris from the
H. Headlight — Used to operate the snow thrower in poor lighting

FEATURES AND CONTROLS

E
H
chute deflector (up or down).
reverse. Push down to engage, release to disengage.
discharge chute and the auger housing.
conditions.
D
G
Figure 10
