Overdrive Section
Controls
LED
Inputs (TS 3.5 mm)
OSC 1
OSC 2
OSC 1&2
INVERT IN
SHAPE 1
SHAPE 2
PULSE WIDTH 1
PULSE WIDTH 2
VCF IN
FREQ MOD
RESONANCE
OVERDRIVE IN
VCA IN
VCA CV
DELAY IN
DELAY TIME
E GATE 1
E GATE 2
SAMPLE & HOLD IN
SAMPLE & HOLD CLOCK
LFO RATE
LFO SHAPE
LFO TRIG
MULT (Multiple)
ATT 1 IN
ATT 1 CV
ATT 2 IN
SLEW IN
SUM1(A)
SUM1(B)
SUM2(A)
SUM2(B)
Drive: 0 to 11
Tone: 0 to 10
Level: 0 dB to -∞
Drive amount indicator
Control voltage: 1 V per octave
Control voltage: 1 V per octave
Control voltage: 1 V per octave
inverts voltage
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V
Signal input
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V
Signal input
Signal input
Control voltage: -9 V to +9 V
Signal input
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V (envelope triggers @ 1.5 V)
Control voltage: -5 V to +5 V (envelope triggers @ 1.5 V)
Signal input
Control voltage: -5 V to +5 V (S&H triggers @ 3 V)
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V
Control voltage: -5 V to +5 V (S&H triggers @ 1.6 V)
Input Signal is duplicated on Mult 1 and Mult 2 outputs
Signal input
Control voltage: -5 V to +5 V
Signal input
Signal or CV input
Signal input or CV input
Signal input or CV input
Signal input or CV input
Signal input or CV input
