4) Turn the hanger bolts into the hole / anchors until the thread still pro-
5) Pull the cable through the prepared openings on the charging station.
6) 4 of the supplied washers can be used to compensate for any uneven-
7) Position the charging station on the wall and secure it with the 4 wash-
The charging station is now mounted on the wall and ready for cabling.
Installation manual V1.05
© EATON
trudes approx. 20 mm
Pay attention to leak tightness!
ness and to ensure proper water flow behind the device: If necessary,
place the washers 1
ers 3 and nuts 4 to the hanger bolts
Mounting and installation instructions
x .
on the hanger bolts.
5 .
