Technical Data

Overview - Autoclave

Ambient temperature
Volume of the autoclave chamber
Maximum charge
Sterilization cycle
Venting
Max. Working pressure
Test pressure
Chamber designed according to
Voltage
Power
Interference suppression classification

Directives

•
Low-voltage-directive 2014/35/EU
Certoclav MultiControl constructed according Low-Voltage-Directive 2014/35/EU.
Tested in accordance with:
EN61010-1:2001 (IEC 1010-1:2001) Safety requirements for electrical equipment for measurement, control and
laboratory use – Part 1: General requirements
EN61010-2-040:2005 (IEC 1010-2-040:2005) Particular requirements for sterilizers and washer-disinfectors
used to treat medical materials
•
Electromagnetic Compatibility Directive 2014/30/EU
Associated standars:
EN 61326-1:2013 Electrical Equipment for measurements, control and laboratory use - EMC-Requirements Part
1: General requirements
EN 61000-3-2:2006 + A1:2009 + A2:2009 Electromagnetic Compatibility (EMC) — Part 3- 2: Limits - Limits for
harmonic current emissions (Equipment input current equal to or less than <= 16A per phase)
EN 61000-3-3:2013 Electromagnetic Compatibility — Part 3- 3: Limits — Limits for voltage fluctuation and
flicker on the public low-voltage system (equipment having an input current to or less <= 16 A per phase), and
not subject to conditional connection.
EN 61010-1:2010
•
RoHS 2011/65/EU: Directive on the restriction of the use of certain hazardous substances
Microbiological test certificate and air removal test by Österreichische Bundesstaatliche Bakteriologisch-
Serologische Untersuchungsanstalt, Vienna (Federal Austrian Bacteriological and Serological Research
Institute), Institute for Applied Hygiene, Graz (Institute of Applied Hygienic, Graz) and ANAWA, Munich.
CERTOCLAV MultiControl is not suitable for sterilization of tight sealed bottles and loads with aggressive
media. For porous loads the CERTOCLAV MultiControl can' t be recommended. Smaller amounts of
textiles with low density can be sterilized. Liquids can only sterilized in small amounts. Large amounts will
not reach the required temperature. Please contact CertoClav for special firmware versions if you want to
sterilize liquids.
CertoClav Sterilizer GmbH
Peintner Strasse 10
A-4060 Leonding / Austria
www.certoclav.com
-10°...+40°C
12 L or 18 L
9 kg with max. 3 L water inside
as programed
Flow process with fractionation
2,7 Bar
4,1 Bar
Low-voltage-directive 2014/35/EU
230V ~10% 50 Hz
Controller: 5,5 W, Heating: 1900 W
N
