REMINDERS FOR THE INSTALLER

The manufacturer will not be liable for any damage or
injury resulting from failure to observe the following
rules.
•
Read this manual carefully. It provides important
information for safe installation, use and maintenance
of the appliance.
•
Installation, conversion to a different type of gas
and appliance maintenance must be carried out by
qualified technicians authorized by the manufacturer,
in compliance with current safety standards and the
instructions given in this manual.
•
Identify the specific appliance model. The model
number is detailed on the packaging and on the
appliance data plate.
•
The appliance must be installed in a well-ventilated
room.
•
Do not obstruct any air vents or drains present on the
appliance.
•
Do not tamper with appliance components.

6. REFERENCE STANDARDS AND LAWS

Install the appliance in compliance with current safety
regulations.
Install the appliance in compliance with current regulations.

7. HANDLING

The packaging is marked with warning symbols that indicate
the precautions to be taken when handling the appliance
to avoid damage.The appliance must only be handledusing
suitable equipment. If lifting equipment is used, such as
forklift trucks or similar, make sure that the appliance is in a
stable position.

8. UNPACKING

Check the state of the packaging and in the event of
damage, ask the delivery person to inspect the goods.
•
Remove the packaging.
•
Remove the protective film from the exterior and interior
panels. Use a suitable solvent to remove any residual
adhesive from the panels.

9. POSITIONING

•
The overall dimensions of the appliance and the
position of connections are given on the installation
diagram at the start of this manual.
•
The appliance can be installed singly or in combination
with other appliances in the same product range.
•
The appliance is not suitable for integrated installation.
•
Position the appliance at least 10 cm from adjacent
walls. This distance can be reduced in the presence of
non-combustible walls or heat-insulated walls.
•
Level the appliance by means of the heightadjustable
feet.
•
The countertop appliance weighing less than 40kg,
where installed singly, must be secured using the
flanged feet provided.
APPLIANCE ASSEMBLY WITH BASE
Follow the instructions provided with the type of support
utilized.

Instructions for installation

JOINING APPLIANCES TOGETHER IN LINE
•
•

11. CONNECTIONS

The position and dimensions of connections are given in the
installation diagram at the start of this manual.
ELECTRICAL CONNECTIONS
Check that the appliance is designed to operate at the
voltage and frequency of the power supply present on site.
Check the details given on the appliance data plate.
If used, the symbol
CAUTION - HAZARDOUS VOLTAGE.
•
•
•
•
•
•
PROTECTIVE EARTH AND EARTH BONDING
CONNECTIONS
Connect the appliance to an efficient ground circuit. Connect
the earth conductor to the terminal with the symbol
located next to the main terminal board.
Connect the metal structure of the appliance to the
equipotential node. Connect the conductor to the terminal
with the symbol
This symbol indicates that the appliance must be included
in an equipotential system connected in compliance with
current regulations.

13. COMMISSIONING

See Chapter " INSTRUCTIONS FOR MAINTENANCE".
Place the appliances side by side and adjust the tops to
the same height.
Unite the appliances using the special unionjoint-
coverings supplied upon request
indicates:
Install an adequately rated omnipolar circuit-breaker
upline of the appliance in an easily accessible point,
in compliance with installation regulations; the
circuit breaker must guarantee immediate omnipolar
disconnection from the mains, with a minimum
contact opening that allows complete disconnection
in overvoltage category III conditions. The maximum
permitted current dispersion is 1mA/kW.
For electrical connection, use a rubber-sheathed
flexible cable which is oil resistant, type H05RN-F or
H07RN-F, for cable size consult the technical data
table.
Connect the power supply cable to the terminal board
as shown in the wiring diagram supplied with the
appliance.
Secure the power supply cable with the cable clamp.
Protect the power supply cable on the outside of the
appliance with a rigid plastic or metal pipe.
If the power supply cable is damaged, it must be
replaced by the manufacturer or the technical after-
sales service or, in any case, by a suitably qualified
technician, so as to avoid any risk whatsoever.
on the outside part of the bottom.
