ST40 Kompass
rot +
unisolierte Ader = Schirm -
Spannungskabel
ST40 Wind
rot +
unisolierte Ader = Schirm -
3A Sicherung
12V Span-
nungsquelle
(z.B. Batterie)
rot
grün
Schirm
gelb
blau
3A Sicherung
12V Span-
nungsquelle
(z.B. Batterie)
rot
blau
SVB Spezialversand für Yacht- & Bootszubehör 2008
Kabel vom
Fluxgate-
Kompass-
Sensor
Kabel vom
Windgeber
