15.5

Modbus-Registerzuornung

15.5.1

Registertabelle

Register Parameter
10 Main version
11 Major version
12 Minor version
13 Build-Nr. Software
100 Old status
102 Erster Messwert (PV)
104 Zweiter Messwert (SV)
106 Dritter Messwert (TV)
108 Vierter Messwert (QV)
110 Status
114 Diagnostics
118 PV unit
119 SV unit
120 TV unit
121 QV unit
122 Variable 19 unit
123 Variable 20 unit
199 Additional status
1300 Old status
1302 Erster Messwert (PV)
1304 Zweiter Messwert (SV)
1306 Dritter Messwert (TV)
1308 Vierter Messwert (QV)
1310 Status
1314 Diagnostics
1400 Old status
1402 Erster Messwert (PV)
1404 Status
1414 Zweiter Messwert (SV)
1416 Status
1426 Dritter Messwert (TV)
1428 Status
1438 Vierter Messwert (QV)
1440 Status
2000 Old status
2002 Erster Messwert (PV)
2004 Zweiter Messwert (SV)
2006 Dritter Messwert (TV)
Datentyp Swap-Modus Beschreibung
UINT16 - Main firmware version code
UINT16 - Major firmware version code
UINT16 - Minor firmware version code
UINT16 - Firmware build number
UINT32 - Only zeros
UINT32 CDAB First HART variable
UINT32 CDAB Second HART variable
UINT32 CDAB Third HART variable
UINT32 CDAB Fourth HART variable
UINT64 - See "Format of the status bytes" →  205
UINT64 CDAB See "Format of the diagnostic bytes" →  204
UINT16 - Unit of the first HART variable
UINT16 - Unit of the second HART variable
UINT16 - Unit of the third HART variable
UINT16 - Unit of the fourth HART variable
UINT16 - Unit of variable 19
UINT16 - Unit of variable 20
UINT16 - • 1: Device locked
• 2: Device unlocked
UINT32 - All zeros
UINT32 CDAB First HART variable
UINT32 CDAB Second HART variable
UINT32 CDAB Third HART variable
UINT32 CDAB Fourth HART variable
UINT64 - See "Format of the status bytes" →  205
UINT64 CDAB See "Format of the diagnostic bytes" →  204
UINT32 - All zeros
UINT32 CDAB First HART variable
UINT64 - See "Format of the status bytes" →  205
UINT32 CDAB Second HART variable
UINT64 - See "Format of the status bytes" →  205
UINT32 CDAB Third HART variable
UINT64 - See "Format of the status bytes" →  205
UINT32 CDAB Fourth HART variable
UINT64 - See "Format of the status bytes" →  205
UINT32 - All zeros
UINT32 ABCD First HART variable
UINT32 ABCD Second HART variable
UINT32 ABCD Third HART variable
