2. INSTALLATION ACCESSORY

Precaution of install the wire controller
1. This manual provides the installation method of wire controller. Please refer to the
wiring diagram of this installation manual to wire the wire controller with indoor unit.
2. The wire controller working in low voltage loop circuit. Forbid to directly contact the
cable of 220Vcommercial electricity or of 380V high voltage, and don't wire this kind
of wire in the said loop; wiring clearance between configured tubes should at the
range of 300~500mm or above.
3. The Shielded wire of the wire controller must be grounded reliable.
4. Upon finish the wire controller connection, do not employed tramegger to detect the
insulation.
5. The connective cable of wire controller should not be longer than 20 meters.
