3. INSTALLATION METHOD
7.Reattach the upper part of the wire controller
After adjusting the upper case and then buckle the upper case; avoid clamping the
wiring during installation. ( Fig 3-1 1)
All the pictures in this manual are for explanation purpose only.
Your wire controller may be slightly different .The actual shape shall prevail.
Fig 3-11
