6 Order data

6 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type
Ball valve body, metal, 3-piece, Sanitary/Hygienic,
ISO 5211, top flange
2 DN
DN 8
DN 10
DN 15
DN 20
DN 25
DN 32
DN 40
DN 50
DN 65
DN 80
DN 100
3 Body/ball configuration
2/2-way body
4 Connection type
Spigot EN 10357,series A
Order example
Order option
1 Type
2 DN
3 Body/ball configuration
4 Connection type
5 Ball valve material
6 Seal material
7 Special version
8 CONEXO
GEMÜ BB04
Code 4 Continuation of Connection type
BB04 Spigot ASME BPE
Spigot ISO 1127 / EN 10357, series C
Clamp ASME BPE, face-to-face dimension FTF
Code
ASME BPE
8
10 5 Ball valve material
15 1.4435 / ASTM A351, low ferrite <3% (equivalent to
316L Δ Fe<3%)
20
(body, connection, ball), 1.4409 / SS316L (spindle)
25
32 6 Seal material
TFM 1600 (FDA certification)
40
50 TFM 1600 (FDA certification), cavity filled
65
7 Special version
80
Without
100
ATEX version
Code
8 CONEXO
D
without
Integrated RFID chip for electronic identification
Code
and traceability
17
Code
BB04 Ball valve body, metal, 3-piece, Sanitary/Hygienic,
ISO 5211, top flange
15 DN 15
D 2/2-way body
60 Spigot ISO 1127 / EN 10357, series C
C3 1.4435 / ASTM A351, low ferrite <3% (equivalent to 316L Δ Fe<3%)
(body, connection, ball), 1.4409 / SS316L (spindle)
5T TFM 1600 (FDA certification)
Without
without
28 / 48
Description
www.gemu-group.com
Code
59
60
80
Code
C3
Code
5T
5H
Code
X
Code
C
