Gemü BB04 Betriebsanleitung Seite 35

8.2.3 Spigot ISO 1127 / EN 10357 (connection code 60)
øk
DN øc
8 10.3 13.5
10 14 17.2
15 18.1 21.3
20 23.7 26.9
25 29.7 33.7
32 38.4 42.4
40 44.3 48.3
50 56.3 60.3
65 72.1 76.1
80 84.3 88.9
100 109.7 114.3
Dimensions in mm
www.gemu-group.com
ød s
1.6
1.6
1.6
1.6
2
2
2
2
2 131.5
2.3
2.3 198.5
øk L
42.5 120.1
42.5 120.1
42.5 140.1
54.5 140
60.4 152
75 165
86.5 190
107 203
254
158 280
308
35 / 48
LB LS
L
LB LS
24.3 47.9
24.3 47.9
24.3 57.9
31.2 54.4
34 59
44 60.5
55 67.5
68.9 67
82 86
96 92
122 93
8 Dimensions
H1 n x ØL
37 4 x M6
37 4 x M6
37 4 x M6
40 4 x M8
48 4 x M8
53 4 x M10
63 4 x M12
72 4 x M14
92 4 x M14
102 4 x M16
132 6 x M20
GEMÜ BB04
