tube rotating insidethe other, and not bythe plastictubetuming insidethe
hinge braciets. Check that the rudder is tree to move, and that it can
delLct to the throws stated on the plan on either side. ll it binds up, sand
back the rudder leading edge, or pull the hinge brackets out ol the fin
slightly. wllen the rudder is rotated, the gap between the rudder leading
edöe änd the fin sides should be no greater than 1.5 m m However' the
rudler must on noaccount rub on thelin sides. Checkalignmentand free-
dom ot movementagain, then pullout the hingetube. Caretult remove the
rudder, taking care not to alterthe position ot the hinge brackets, and glue
the brackets into the stem post, using instant glue.The steelrod forrudder
actuation is 1.3 m.m. O by 1250 m.m. long; bend one end as shown on the
olan and slide it into the lett-hand bowden cable outerlrom the tailend Frt
ihe rudderand markthe position ofthe rudderhom onthe rudder' File out
a slot in the rudderto take the hom. Notethe position ofthe hom, as shown
on the plan. The point at which the pushrod engages must be alignedwith
the rudder hinge line. The distance from the hinge line to the rudder
pushrod engagement point should be 12 m.m. The horn itself is not glued
into ptace until the rudder has been covered.
The next steo is to set u D lh e elevator. Press the hollow rivet into the hole in
the tailplane, and fixthetailplane tothefin, using plastic screw 21. Measure
the distance trom each tallplane tip to the centre of lhe fuselage nose; it
must be the same on each side. Draw round the top of the lin on the tail-
plane support, and unscrew lhe tailplane. Orive in a selt-tapping screw
(2.2x6.5 m.m.) where marked on the tailplane seat 19. Measurethe €xact
location ofthe screw head on the tailplane, andtranslerthe position to the
tailplane seat. Drilla 4 m.m. O holewhere marked. Screw the tailplane into
place again, and recheck that it is aligned squarely. lf necessary, file out
the hole lorthe hollow rivet. when satisfied, glue the hollow rivet in place
with s-minute epory. Whilethe resin issetting, screwthetailplane ontothe
fin and check that it is still aligned conectly.
,-,incidence oI the tailplane is checked next Placethe fuselage on a flat
surface with the fin exactly upright. Measure the distance from the table
surtaca to the centreline otthe tailplane leading edge and the centreline ot
the trailing edge spar, at the root ol the tailplane. To do this, mark the
centrelines on the tailplanewith a pencil The distance from the table to the
leading edge centreline mustthen be 342 m m.,and the distance from the
table to the trailing edge centreline must be 335 m.m. Please measure
these dimensions very carefully, as theflight performance ofthe ASW 22
deDends to a considerable extent on the conect incidence setting. lf
necessary, trim backthe tailplane seat. Screw the tailplane tothefin, and
add any small hardwood wedges underthe tailplane untilthe dimensions
are conect. Gluethese piecestothetailplane seat. Now cover the tailplane
seat with sellotape, and apply a th in coat af wax or oil to it to act as a r€lease
agent. Cut out holes in the tape for the plastic screw and the locating
screw. Mix up a polyesterfiller paste and apply it to the plywood tailplane
support on thetailplane. Screwthetailplaneto the fin, and wipe olf excess
filler oaste. Let the filler harden and then unscrewthe tailplane. Sand the
filler smooth.
Wn98
Splice the leading edge 49 for each wing panellrom two strips of 8 x 15 x
1d30 m.m. wood. Glue the leading edgetothe wing panel, using white glue
'
tninuteepoxy. Hold the leading edge in placewith sellotap€ while the
gioJ'sets. The wings of the ASW 22 have compound dihedral, so the
;hange in angle atthe aileron root point is intentional, and not a lault Sand
the leading edge to lollow the wing seclion. Gluethe wing tips 52 in place
and sand them down. Separate the allerons trom the wings as shown on
the Dlan. The chordwise cuts at either end of the aileron must be exactly
paratlel with the fuselage centreline. Remove 7 m.m. ftom each end otthe
aileron, to allow for the end sealing pieces 51, wh ich are fitted later' Before
facing strips 50 are titted, the rounded comers caused by the machining
oroc;ss have to betrimmed square Sandthemtoasharp comer,and glue
tacing strlp 50 to the wing cut-out, using white glue or s-minute epory'
Sand the strip flush with thewing surface. Be sure lo leave a sharp comer
at the top rear edge, which constitutes the aileron hinge line Glue facing
strip 50 io the btding edge of the aileron, and sand it back flush Here
agäin the sharp top edge isimportant.Gluesealing pieces 5l totheends ot
th; aileron and to the ends ollhe aileron recess inthewing, cutting pieces
from the strip supplied. Sand them back tlush when the glue is dry Otler
uD the ailerons; the gap at either end should be about 1 m.m
Ailercn. b€llcrank! See Page 6 @
Drilta 3 m.m. g hole in the bellcrank support plate 53. Mountthe b€llcrank
54onthe plywood plate,using bush 55, and the M 3 x 12 m.m. countersunk
head screw and nut 57. Lockthe nut with 5-minute epory. Checkthat the
bellcrank rotat$ lreely. Belore the crank is installed a certain amount of
foam has to be removed trom the wing in the area around the bellcrank
well, as shown on the ptan. Dothiswith care, to avoid damaging thewing'
Pass a 1.3 m.m. O, 1250 m.m. long steel pushrod into the wing-mounted
bowden cable outer lrom the root, pushing it in as faras the bellcrankwell'
Pullthe end otthe steel rod out of the wing slightly, and solder a thr€aded
muoleronto the end, alter roughening up and bendingthewire slightly, as
described before. Screw a metal quicklink onto the coupler, and lock it on
the threads with adrop otglue. Connectthequicklinktothe bellcrank, and
fit the bellcrank support plate into th€ wing. Check that the crank works
properly, and remove small amounts of loam to avoid any tendency to jam
u o. ThJbellcrank and its push rod musl not come into contact with foam at
any point. When working on the starboard wing, please not€ that the bo!'-
den cable outer sleeve must end about
'15 m.m. short of the root rib' i e'
inside the wing. The sleeve is usually free to move inside thewing lfthis is
not the csse, tullout the steel pushrod and twist a smallround needlefile
into the outer. Release the outerlrom the sheeting by gentlytwisting itto
and fro. On no account use torce here. The outer sleeve can now be pulled
out stightlyto shorten it. Do not pullittoofar, otherwise you willfind itdiffi-
cult to retum. Set the bellcrank to the neutral position, and markthe exit
Dosltion of the th readed pushrod 58on thewing facing strip. Using a round
iile, cut atunnelfrom the facing strlpthrough tothe b€llcrankwellthrough
the foam. Scr€w a quicktink onto the rod. Bend the threaded pushrod to
the shaoe shown on the plan, and pass ths rod through the tunn€l;
connect the quicklink to the bellcrank as shown on the plan.
Check the linkage lor corect operation, and bend the threaded pushrod
slightly if necessary until all is in order. Temporarily fit the aileron to the
wing, using strips of sellotape, and mark the position ol the aileron hom
from the exit ooint of the th readed pushrod. File a slot in each aileron, sand
the hom to shape (see plan), and check itforfit in the slot Drilloutthehom
hole to 1.7 m.m. O. Roughen up the gluing surlace otthe hom and glue it in
Dlace with s-minute epory. Apply sellotape to the aileron on eithersid€ ol
ihe hom, so thal excess epoxy does not spoil its appearance The position
oI the homs must be identical on both ailerons, to ensure equal aileron
lhrowon both wings. The centre of the hom hole must be 10 m.m' ftom the
aileron hinge axis. Set the bellcrank and aileron to neutral and bend the
thread€d rod at nght-anglesattheconect point. Snip otf the excess length
of rod and conneclthe rod tothe aileron hom. Bellcrank support plats 53
can now be glued in place. Seatotlthe bellcrank wellwith balsa sheet 59;
the grain sh;uld run along the wing. Take care not to allow glue onto the
bell;rankwhen gluingthe ssaling piece in place. Sand piece59fiushwith
the wing surface when the glue is dry.
The ASW 22 wing panels are factory-prepared forthe installation of aiöra-
kes. The aiörakes units (Order No.72 2641) are notsupplied inthe kit' but
we strongly recommend that you fit them as a means of controlling the
glide angle on the landing appoach They make it possibl€ to land sately
;ithout great ditficulty even in confined spaces. We urge you strongly not
to omit the airbrakes. lf, however, you decide against fitting th€m, then the
ore-cutairbrakew€llhasto be sealed. To dothis glue in-flllstrip 63 intothe
slot. Run a line ot ißtant glue round the d ie-cut aiörake capoulline in part
64, and glue thls piece into the wing sand flush with the wing when dry'
Alörske inEt lhion See Page 6 @
Cut steel Dushrod 61 (0 8 m.m. O) in half, and slide one rod from th€ rcot
end ol the wing into th€ airbrake bowden cable out€r as far as the aiÖrake
well. Here again - as described in the aileron installation section
- a little
foam will need to be removed. Bend the rod asshown on the plan, and con-
nect it to the aiörake actuation lever. Fittheaiörake unit intothe aiörake
well.The unitshould be an easyslidingfit.Itnecessary,
sand backthe foam
insid€ the well, using a flat sänding sticK until the unit can be fitt€d with
light finger pressure. Do not use lorce, asthis willpress the aiörakssides
iriward, and Sop it lunctioning. lt may b€ necessary to bend the aiörake
end of the pushrDd slightly, as manufactuting tolerances preclude dead
accurate fitting otthe outertube in the wing. Checkthatthe unitfunctions
freely, and re;ove it ftom the wing. Beloregluingthe airbrake unitintothe
wing, it is essentialto cany oul one smalljob, which guarantees thatthe
aiörake will work taultlessly; seal otf the outside ends ol the aiörake pivot
shafts with smallpiecesofsellotap€, so that it i8 not possiblelorgluetojam
them up. Glue the aibrake unit into the wing, using 5-minute epory, and
checkthe unit for conect operation now and thenwhileths glue is setting'
Glue the sealing strip 64 in ptace, with the dle-cut side uppermost' and
carefully separate thedie-cut portion with a shatp balsa knlle The separa-
ted strip is then glued to the top of the aiörake with contact cemer , and
the balsa parts sanded backflush with thewings. Checkagain thattheair-
brake works conectly, and trim the balsa strips as nece$ary to provide
clearance. In the case of the staöoard wing panel, the aiörake bowd€n
cable outer sleeve must be rece$ed 15 m.m. insidethe wing, as with the
aileron ouler. Pull it oul, cut it short, and push it back insidethewing The
wing joiner blade 67, locating pin 68 and root rib 69 are fitted at a later stage
of construction.
