6. Circuit Diagram

PCB1
PTC
Unit fitted with a 20 x 5mm 1 Amp fuse as standard.
It is the customers responsibility to change the fuse to suit their own application.
Type 508 Installation Manual
Chassis
Earth
PLATFORM
Cover
Earth
FTB FS1
L
E
N
Spare
TB1
Page. 4
