NOTICE:
power tool can differ from the declared value in which the
tool is used; In order to protect the operator, user should
wear gloves and ear protectors in the actual conditions
of use.
Recommended Blade
PART NAME
Brush Butter Blade

PACKING LIST

PART NAME
Brush Cutter Attachment
Blade and Blade Sheath Set
Guard
Guard Accessory (For use with trimmer
head ONLY)
Hex Wrench
Multi-Function Wrench
Operator's Manual
DESCRIPTION
KNOW YOUR BRUSH CUTTER ATTACHMENT (Fig. A)
1. End Cap
2. Brush Cutter Shaft
3. Guard
4. Blade
5. Blade Sheath
6. Clamp Wire
7. Sealing Screw
8. Gear Case
9. Shaft-locking Hole
10. Outer Flange
11. Multi-Function Wrench
12. Hex Wrench
13. Guard Accessory (For use with trimmer head ONLY)
WARNING:
firmly in place. The guard must always be on the tool to
protect the user.
WARNING:
equipped with a trimmer head, the guard accessory
should be mounted onto the guard. Failure to comply
could result in an overly long cutting line and motor
overload.
Downloaded from www.Manualslib.com
The vibration emission during actual use of the
MODEL NUMBER
ABB1203
Never operate the tool without the guard
When the tool is used as a line trimmer,
manuals search engine
ASSEMBLY
WARNING:
If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING:
Do not attempt to modify this product
or create accessories not recommended for use with this
brush cutter. Any such alteration or modification is misuse
and could result in a hazardous condition leading to
possibly serious personal injury.
WARNING:
Always wear heavy gloves when
installing or removing the blade or the guard or doing any
QUANTITY
maintenance on the blade. Be careful of the blade and
protect your hands from being injured by the blade.
1
1
WARNING:
Do not connect to power head until
1
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
1
NOTICE:
The correct assembly sequence of the brush
1
cutter attachment is mounting the guard first, and then
1
the blade, and finally attaching to the power head.
1
WARNING:
Never operate the tool without the guard
and the front-assist handle with barrier bar firmly in place.
Failure to comply could result in possible serious personal
injury.
MOUNTING THE GUARD
1. Lift the brush cutter head and face it downward;
align the two mounting holes in the guard with the
two bolts that are preassembled on the fixing board.
Make sure that the internal surface of the guard
faces towards the brush cutter head (Fig. C).
2. Lock the guard in place with the bolts and the
supplied hex wrench (Fig. D).
MOUNTING THE BLADE
1. The blade is shipped with a sheath. Before mounting
the blade onto the brush cutter, the sheath should be
removed by undoing the clamp wire from the hook on
the sheath (Fig. E).
Fig. E parts description see below:
E-1 Hook
E-2 Clamp Wire
BRUSH CUTTER ATTACHMENT — BCA1200
EN
9
