2. Rotate the outer flange to align the slot in the inner
EN
3. Insert the hex wrench provided into the aligned holes
4. Position the brush cutter head against a solid surface
5. Mount the blade onto the motor shaft, ensuring that
6. Rotate the outer flange to align the slot in the inner
7. Position the brush cutter head against a solid surface
Use of Guard Accessory
NOTICE:
equipped with a trimmer head, the guard accessory must
be mounted onto the guard (Fig. K).
Secure the guard accessory onto the guard by tightening
the three screws with the hex wrench provided. Failure
to comply could result in an overly long cutting line and
motor overload.
10
Downloaded from www.Manualslib.com
flange with the shaft-locking hole in the gear case
(Fig. F).
to act as a stabilizer (Fig. G).
Fig. F & G parts description see below:
F-1 Gear Case F-3 Outer Flange
F-2 Aligned Shaft-locking G-1 Stabilizer
Holes
for support. With one hand grasping the brush cutter
shaft and use the other hand to grasp the multi-
function wrench provided to loosen the nut in the
direction of the arrow marked on the outer flange and
remove the nut and the outer flange. Save them for
reassembly (Fig. H).
the surface of the blade is flush with the surface of
the inner flange bulge. Go on mounting the outer
flange and the nut (Fig. I). Pre-tighten the nut in
COUNTERCLOCKWISE by hand.
Fig. I parts description see below:
I-1 Inner Flange Bulge I-4 Outer Flange
I-2 Motor Shaft I-5 Blade
I-3 Nut
flange with the shaft-locking hole in the gear case
and insert the hex wrench provided into the aligned
holes to act as a stabilizer as previous step 2 & 3
shown.
for support. With one hand grasping the blade and
use the other hand to grasp the multi-function
wrench provided to tighten the nut opposite the
direction of the arrow marked on the outer flange
(Fig. J).
When the tool is used as a line trimmer
BRUSH CUTTER ATTACHMENT — BCA1200
manuals search engine
CONNECTING THE BRUSH CUTTER ATTACHMENT TO
THE POWER HEAD
This brush cutter attachment is designed for use with EGO
Power Head PH1400E.
See "INSTALLING AN ATTACHMENT TO THE POWER
HEAD" section in the power head PH1400E operator's
manual.

OPERATION

WARNING:
Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
WARNING:
Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
APPLICATIONS
You may use this product for the purpose listed below:
◾
Cutting malted grass, weeds, wild growth and scrub,
thinning young stands with a maximum stem diameter
of 2cm.
NOTICE:
The tool is to be used only for its prescribed
purpose. Any other use is deemed to be a case of misuse.
USING THE BRUSH CUTTER WITH POWER HEAD
WARNING:
Dress properly to reduce the risk of
injury when operating this tool. Do not wear loose clothing
or jewelry. Wear eye and ear/hearing protection. Wear
heavy, long pants, boots and gloves. Do not wear short
pants or sandals or go barefoot.
For safe and better operation, put on the shoulder strap
across the shoulder. Adjust the shoulder strap in a
comfortable operating position. Hold the brush cutter
with one hand on the rear handle and the other hand on
the front-assist handle. Keep a firm grip with both hands
while in operation. The brush cutter should be held at
a comfortable position with the rear handle about hip
height. Maintain your grip and balance on both feet.
Position yourself so that you will not be drawn off balance
by the kickback reaction of the cutting blade (Fig. B).
WARNING:
The shoulder strap is also a quick
release mechanism in hazardous situation. When
emergency occurs, take it off from your shoulder
immediately, no matter what way the strap is in.
