Allowable positioning (
► INFORMATION: For bench alignment, the 4R10 is positioned at the
same height for each version. The distance to the prosthetic socket
(h
= h
) or to the alignment reference point of the prosthetic knee joint
1
2
(h
= h
) is always the same. The instructions for use of prosthetic sport
3
4
feet provide information whether a different height has to be used for the
bench alignment of a sports prosthesis due to the spring effect.
Position the product in the prosthesis according to the examples in Fig
6
ure
on page 7 ( : allowable).
→
: Recommended position (close to the TT prosthetic socket or
prosthetic knee joint) – this positioning offers the most alignment
possibilities.
→
: Alternative position (close to the prosthetic foot) – this position
ing shifts the centrifugal mass in the distal direction, but reduces
the alignment possibilities and makes it more difficult to install a
cosmetic cover.
Using the spacer plate (
► INFORMATION: The system height can be changed with the spacer
plate.
Only use or omit the spacer plate according to the illustrated, approved
examples in reference to the socket adapter ( : flat contact surface;
: allowable;
Mounting the socket adapter (
► CAUTION! Thread lock is only required when finishing the prosthesis.
Install the socket adapter in the illustrated sequence.
7.3 Optimising the static alignment
► Optimise the static alignment of the prosthesis with its various distal
prosthetic components according to the values in the instructions for use
of the products that are used.
7.4 Optimising during dynamic trial fitting
► During the dynamic trial fitting, test and optimise the prosthesis with its
various distal prosthetic components.
CAUTION! If the settings of the prosthesis with its various distal pros
thetic components exhibit opposing effects, the safety-related aspects
always have to take precedence over everything else in choosing a com
promise setting.
6
on page 7 – )
7
on page 8 – )
: no flat contact surface;
8
: prohibited).
on page 9 – )
25
