Technical data
ControlCenter-Compact-32C
Interfaces
Main power supply
Redundant
power supply
Housing
ControlCenter-Compact-48C
Interfaces
Main power supply
Redundant
power supply
Housing
ControlCenter-Compact-64C
Interfaces
Main power supply
Redundant
power supply
Housing
ControlCenter-Compact-80C
Interfaces
Main power supply
Redundant
power supply
Housing
28 · G&D ControlCenter-Compact
Downloaded from www.Manualslib.com
Dynamic ports:
Current consumption:
Current consumption:
Dimensions (W × H × D):
Dynamic ports:
Current consumption:
Current consumption:
Dimensions (W × H × D):
Dynamic ports:
Current consumption:
Current consumption:
Dimensions (W × H × D):
Dynamic ports:
Current consumption:
Current consumption:
Dimensions (W × H × D):
manuals search engine
32 × RJ45 socket
100-240V/60-50Hz, 0.7-0.4A
100-240V/60-50Hz, 0.7-0.4A
435 × 44 × 211 mm
48 × RJ45 socket
100-240V/60-50Hz, 0.8-0.4A
100-240V/60-50Hz, 0.8-0.4A
435 × 88 × 211 mm
64 × RJ45 socket
100-240V/60-50Hz, 0.8-0.4A
100-240V/60-50Hz, 0.8-0.4A
435 × 88 × 211 mm
80 × RJ45 socket
100-240V/60-50Hz, 0.9-0.4A
100-240V/60-50Hz, 0.9-0.4A
435 × 88 × 211 mm
