Expanding switchable signals

Adjusting the bus address of matrix switches

The primary matrix switch automatically makes the stack matrix switches access the
same port that the user accesses at the primary matrix switch.
This requires the correct setting of the bus address in the individual matrix switches.
How to change the bus address of a matrix switch:
1. Click on
2. Right-click the matrix switch and click the
menu.
3. Choose
4. Choose
primary:
satellite 1 ... 9:
5. Press
24 · G&D ControlCenter-Compact
Downloaded from www.Manualslib.com
KVM Matrix systems > [Name] > Matrix switches
System and press Enter
Bus address and select one of the following options:
The central module is operated by the user.
It switches the satellite matrix switches automatically.
Assign the addresses continuously to the individual stacking
matrix switches.
OK to close the window.
manuals search engine
in the tree view.
Configuration
.
entry on the context
