en 28 | MT 788 | User information
2.

User information

2.1

Important notes

Important information on copyright, liability and warran-
ty provisions, as well as on equipment users and compa-
ny obligations, can be found in the separate manual "Im-
portant notes on and safety instructions for Beissbarth
Tire Service Equipment". These instructions must be
carefully studied prior to start-up, connection and opera-
tion of the MT 788 and must always be heeded.
2.2

Safety instructions

All the pertinent safety instructions can be found in the
separate manual "Important notes on and safety instruc-
tions for Beissbarth Tire Service Equipment". These
instructions must be carefully studied prior to start-up,
connection and operation of the MT 788 and must al-
ways be heeded.
2.3

Electromagnetic compatibility (EMC)

The MT 788 satisfies the requirements of the EMC di-
rective 2004/108/EG.
i
The MT 788 is a class/category A product as defined
by EN 61 326. The MT 788 may cause high-frequency
household interference (radio interference) so that
interference suppression may be necessary. In such
cases the user may be required to take the appropri-
ate action.
|
932 655 638 2014-02-14
3.

Product description

3.1

Intended use

The MT 788 is a wheel balancing machine with mecha-
nical attachment for the balancing of passenger vehicle
and commercial vehicle wheels (trucks, buses and trac-
tors) with a rim diameter of 10" – 30", a rim width of
1" – 20" and a maximum weight of 160 kg. The MT 788
is to be used exclusively for this purpose and solely
for the range of applications specified in these inst-
ructions. Any other purpose is not consistent with the
intended use and is therefore not permissible.
i
The manufacturer cannot accept any liability for pos-
sible damage arising from improper use.
3.2

Prerequisites

The MT 788 must be installed on a flat surface
made of concrete or similar material and anchored in
position.
i
An uneven or vibrating surface can lead to inaccurate
unbalance measurements.
3.3

Scope of delivery

Designation
MT 788
Quick-action clamping nut
Centering flange
Spacer ring for commercial vehicle flange
Commercial vehicle flange
Centering cones (3x) and adapters
Manual vernier caliper
Weight pliers761 629 400
Measuring compasses761 629 400
Calibrating weight
Clamping nut
Wheel spider
3.4

Special accessories

Designation
Wheel lift
Set of quick-action clamping cones M10x1.25 761 612 100
Third centering cone dia. 89 to 132 mm
Fourth centering cone dia. 120 to 174 mm
Spacer ring for rims (large rim offset)
Three-arm flange for light commercial
vehicles
Infinitely variable universal flange for cars
(3-4-5 hole)
Calibration weight (calibrated)
Order number
Refer to rating
plate
1 695 616 200
931 144 008
1 695 652 902
1 695 652 901
–
1 695 629 400
761 606 500
1 695 652 870
761 654 377
1 695 626 700
1 695 626 800
Order number
1 695 900 004
1 695 653 449
1 695 606 300
766 606 200
761 653 420
761 654 043
1 695 654 376
