EN
with regulating inserts in the return (2 up 20 heating circuit connections)
Read installation and operating instructions
carefully before installing the brass distribu-
tor/collector "Multidis SFI"
The installation and operating instructions as
well as all other valid documents have to remain
with the user of the system
Content:
1. General information ................................... 7
2. Safety notes............................................... 7
3. Transport, packaging and storage..............8
4. Technical data............................................ 8
5. Construction and function ......................... 8
6. Installation.................................................. 9
7. Operation ................................................. 10
8. Warranty .................................................. 10
9. Chart ........................................................ 11
10. Summary with system components........ 12

1. General information

1.1 Information regarding installation and oper-
ating instructions
These installation and operating instructions serve
the installer to install the brass distributor/collector
"Multidis SFI" professionally and to set it into opera -
tion.
Other valid documents:
Manuals of all system components.
For an overview of our global presence visit
www.oventrop.com.
Subject to technical modifications.
141445280 06/2018
Brass distributor/collector "Multidis SFI"
for industrial surface heating and cooling systems,
Installation and operating instructions for the specialised installer
1.2. Keeping of documents
These installation and operating instructions
should be kept by the user of the system.
1.3. Symbol explanation
Safety guidelines are displayed by symbols. These
guidelines are to be observed to prevent accidents,
damage to property and malfunctions.
Potential dangerous situation for product,
system and environment
Useful information and notes
1.4. Copyright
The installation and operating instructions are
copyrighted.

2. Safety notes

2.1. Correct use

Operating safety is only guaranteed if the brass
distributor/collector "Multidis SFI" is used correct-
ly.
The brass distributor/collector "Multidis SFI" is
used in large industrial surface heating and cooling
systems for the distribution, isolation and regula-
tion of flow rates.
Any use of the product outside the above circum-
stances will be considered as non-compliant and
misuse.
Claims of any kind against the manufacturer and/or
its authorised representatives due to damages
caused by incorrect use cannot be accepted.
The observance of the installation and operating
instructions is part of the compliance terms.
Valves, controls + systems
DANGER
Imminent danger to life and limb
ATTENTION
NOTE
7
