HANDBUCH
Basis AB 2000-1
Basis AB 2000-6
Basis AB 4001-1
Basis AB 4001-6
INHALT
Vorwort.......................................2
Übersicht.....................................2
Produktbeschreibung..............2
Heizen/Kühlen-Funktion .........2
Infosymbole .............................2
Das System 24 V.......................3
Systembeschreibung ...............3
Sicherheitshinweis ...................3
Das System 230 V.....................3
Sicherheit....................................4
Sicherheitshinweise .................4
Lieferumfang 230 V ................4
Lieferumfang 24 V ..................4
Montageanleitung .....................5
Wandmontage.........................5
Montage auf Tragschiene .......5
Die 230 V / 24 V Systeme sind in Bezug auf Ausstattung und Funktion
24 V
weitgehend identisch. Unterschiedliche Eigenschaften sind im gesam-
230 V
ten Handbuch durch Symbole eindeutig gekennzeichnet!
Netzanschluss 230 V ................6
Anschluss 24 V .........................6
Regleranschluss .......................6
Installation der Regler ............7
Anschluss der Antriebe ...........7
Betriebsanleitung.......................8
Funktionsanzeigen ..................8
Heizprogramme ......................8
Austauschen der Sicherung ....8
Technische Daten .......................9
Technische Daten.....................9
Störbeseitigung .....................10
Systemübersicht.....................11
Anhang .....................................11
Urheberrecht .........................11
