Particle spectrum of the medication nebulizer
The site of deposition in the airways or the lungs de-
pends on the droplet size of the medication mist
(aerosol). Aerosol particles with a large diameter are
deposited in the upper airways while aerosol parti-
cles with a small diameter reach the alveoli.
Particle spectrum of Inhalette at a flow of 10 L/min:
F
relative mass distribution [%]
40
30
20
10
0. 1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
2
3
4
5
aerodynamic diameter [µm]
The majority of medication particles have a size of
3.7 µm (MMAD)*. 90 % of the particles are respira-
ble.
F
MMAD [µm]
8
7
6
5
4
3
2
1
2
3
4
5
6
7
The MMAD depends on the set flow. A high flow pro-
duces an aerosol with small particles that penetrate
deeply into the lungs. A lower flow produces an aero-
sol with larger particles that are deposited in the up-
per airways or the nasopharynx where they become
effective.
When using a flowmeter the flow is adjustable so that
the site of medication deposition can be controlled.
*
MMAD = Mass Median Aerodynamic Diameter (median
diameter)
Instructions for use Inhalette
The toggle switch valve (2M85674) has a fixed flow
of 10 L/min and thus produces an aerosol with an
MMAD of 3.7 µm.
Measurement of the aerosol spectrum was carried
out by the Fraunhofer Institut für Toxikologie und
Aerosolforschung (Fraunhofer Institute for Toxicolo-
gy and Aerosol Research).
6
7
8
9
10
20
30
40
8
9
10
20
Flow [L/min]
Order list
Name and description
Inhalette, fixed flow
O
/Air toggle switch valve
2
Adapter for O
flowmeter
2
Adapter for Air flowmeter
*
Spare parts
D
O
/Air connection hose (3 m)
2
N
O
/Air spiral hose (3 m)
2
E
Sealing ring
F
Housing
G
O-ring
H
Nozzle
I
O-ring
J
Atomizer with silicone hose
K
Medication container
L
Nebulizer mask
M
Mouthpiece
F - K Nebulizer element
G - J Set of spare parts
*
The letters refer to the figure in "Overview" on page 13
English
Part no.
2M85674
2M85673
MP01184
MP01185
M17717
MP03322
M05128
2M85568
R27810
-----------
E20566
8404979
2M85201
M11015
M12394
2M85571
2M85567
.
19
