OBID i-scan
5

Operating and Display Elements

5.1 LEDs

Table 5-1 shows the LED configuration.
Table 5-1: LED configuration
Abbreviation
LED V1 (green)
LED V2 (blue)
LED V3 (yellow)
LED V4 (red)

5.2 Reset Button

Pressing the button T1 resets the reader.
FEIG ELECTRONIC GmbH
Installation
"RUN-LED 1"
- Indicates proper running of the internal Reader software
Diagnostic 1: RF communication / EEPROM status
- Short flashing indicates errorless communication with a transponder
on the RF interface
Flashes alternately with V1 after a reset following a software update
-
Flashes alternately with V1 in case of a data error when reading the
-
parameters after a reset
Diagnostic 2: Host communication
- Short flashing indicates sending of a protocol to the host
Diagnostic 4: RF warning
- Comes on when there is an error in the RF section of the Reader.
The error type can be read out via software over the RS232/RS485
interface
Page 46 of 52
Description
ID ISC.MRU200
M70201-4de-ID-B.doc
