Gloria MULTIBRUSH Betriebsanleitung Seite 31

the motor/gear unit (L), as illustrated.
Release the spring-loaded lock (K),
the drive arm is locked when the
locking device independently returns
to its original position
NOTE!
17
If the drive unit (P) cannot be pushed
onto the drive shaft, reach under the
safety guard (O) and turn the hexago-
nal drive until the drive unit (P) slides
onto the drive shaft easily and without
force.
18
Put the surface brush (N) onto the
hexagonal drive and then the guide
arm (M), as illustrated, on the steering
side of the motor/gear unit (L).
19
Now slide the lock (K) into open posi-
tion , hold this and press the guide
arm (M) further onto the coupling shaft
up to the stop. Release the spring-load-
ed locking device (K). The guide arm
(M) is locked when the locking device
independently returns to its original
position .
NOTE!
20
Whilst assembling the surface brush,
make sure that the side part of the
safety guard on guide arm (M) is firmly
connected to the safety guard and is
correctly sealed.
7.1.4 Using the surface brush on
rough surface structures e.g. tiles,
paving slabs, exposed aggregate
concrete, stoneware etc.
Figure 21
21
Place the switched-on device parallel
on the surface to be treated. Hold the
device at working angle and make sure
that the rubber lip on the safety guard
.




RISK OF INJURY FROM RUNNING
BRUSHING TOOL!

7.1.5 Using the surface brush
on wood surfaces (optionally
available as an accessory)
ATTENTION
Improper use of the device poses a risk
of damage to property! You should
therefore observe the following safety
instructions:

32
is just above the ground. Walk at an
even steady pace and push the device
in front of you. Depending on the
degree of soiling, apply light to medi-
um pressure on the surface brush,
adapt your pace of work to the degree
of soiling.
NOTE!
Always work parallel and hold the
device away from your body.
When working close to edges, the
narrower side of the device should
point towards the wall.
In cases of stubborn dirt you can move
the device backwards and forwards on
the spot (like a scrubber), until the
required result is achieved.
Moist cleaning is also possible in cases
of heavy soiling. Use a sprayer to moist
the surface to be cleaned with water or
a cleaning agent, a GLORIA sprayer is
ideal for this purpose. After moit clean-
ing rinse the surface with water.
CAUTION
Never lift the device off the ground
whilst switched on during work as
there is danger of entanglement!
Never use the hard surface brush
with the black bristles for cleaning
wood surfaces, as the hard bristles
attack the surface of the wood,
thereby damaging it.
