Battery power (green LEDs):
Reserve ≤ 30% ≤ 60%
Temperature protection / low voltage
cutoff:
7.1.2 Battery operating time
The service life of the battery mainly
depends on the load applied to the devi-
ce. Any cleaning work performed by app-
lying the brush with high pressure on the
surface to be cleaned will shorten the ser-
vice life of
Another factor is overly frequent starting
and stopping during cleaning, which can
also reduce battery operating time.
Handle battery and device as described in
the instructions.
7.1.3 Assembly of the brushing
tools
Figures 12 - 20
CAUTION
RISK OF BURNS CAUSED BY HOT
PARTS!
During assembly or conversion work
the drive parts of the device or compo-
nents can still be very hot and may
cause burns.
It is therefore important to observe
the following safety instructions:

Wear protective gloves during
assembly!
Disassembly of surface brush followed by
assembly of the joint brush

Switch off the device and remove the
battery (C).
12
Open the locking device (K)
the guide arm (M), as shown in the
illustration.
100%
the battery.
of
31
13
With the lock applied (K) remove the
guide arm (M) and then the surface
brush (N).
14
Now open the locking device (K)
the drive arm (P), as shown in the illus-
tration and remove, with the lock
applied, (K) the drive arm (P) with safe-
ty guard (O).

The surface brush is now successfully
dismantled.
15
Put the guiding wheel (I), as shown in
the illustration, on the steering side of
the motor/gear unit (L). Now slide the
lock (K) into open position
this and press the guiding wheel (I)
further onto the coupling shaft up to
the stop. Release the spring-loaded
locking device (K). The guiding wheel
(I) is locked when the locking device
independently returns to its original
position .
16
Put the pre-assembled joint brush
unit, as illustrated, on the drive side of
the motor/gear unit (L). Slide the lock
(K) into open position
and press the joint brush unit further
into the drive shaft up to the stop.
Release the spring-loaded locking
device (K), the joint brush unit is
locked when the locking device
independently returns to its original
posi tion .
Disassembly of joint brush followed
by assembly of the surface brush

Dismantle the joint brush according to
handling and function described above.
17
Open the locking device (K)
drive arm (P) and, with the lock
applied, (K) put the drive arm (P) with
safety guard (O), onto the drive side of
of
, hold
, hold this
of the
