Delete all DMX assignments [Delete all Fixture patch]
All address assignments and control channel options made can be deleted and reset to the presettings.
1 Call the menu item [Delete all Fixture patch].
2 Select the setting [YES] with the buttons of the lower display if a reset is to be made. Confirm with ENTER.
● The display shortly indicates "SAVE OK" and returns to the main menu level.
Fade Function [Fade mode]
This menu allows adjusting which control channels react on the FADE TIME foot pedal.
1 Call the menu item [Fade mode].
2 Use the buttons of the lower display one of the following options for the fade function:
● [ONLY Dimmer]: only the dimmer channels (incl. colors)
● [ONLY PAN/TILT]: only movements
● [PAN/TILT/Dimmer]: dimmer channels and movements
● [ALL CHANNELS]: all control channels
4 Confirm with ENTER.
● The display shortly indicates "SAVE OK" and returns to the main menu level.
RDM DMX address assignments [RDM DMX Address setup]
This menu allows identifying connected RDM devices and changing their DMX address assignment.
1 Call the menu item [RDM DMX Address setup].
2 Select the setting [YES] with the PAN wheel to access RDM functions and confirm with ENTER.
3 The controller starts searching for RDM devices. The display indicates e.g. "DISCOVER COUNT005" when
five devices have been found.
4 Select the desired device with the buttons of the lower display. The upper display indicates information
regarding the device and the lower display indicates the corresponding DMX address.
5 Use the buttons of the lower display to change the DMX address and confirm with ENTER.
6 Any settings changed will be instantly accepted by the unit.
7 Press the SWAP button to indicate the UID (manufacturer ID and serial number) of the device in the upper
display.
8 Press the DEL button to perform the identify function for the device. The device will send a status response so
that it can be properly identified even if there are multiple identical spotlights.
9 After your settings, return to the main menu level with ESC.
REGARDING RDM
.
● RDM stands for "Remote Device Management" and makes remote control of devices connected to the DMX
bus possible. RDM is an extension of the DMX512 protocol. RDM is especially useful when the device is
installed in a remote area.
● RDM is integrated in DMX without influencing the connections. RDM data is transmitted via the standard XLR
pins 1 and 2 and does not require a new cable type. RDM-ready and conventional DMX devices can be
operated in one DMX line. If DMX splitters are used, they must support RDM.
Data Backup [USB Data backup]
All settings of a light show, i.e. DMX settings, illumination scenes and chases can be stored on a USB memory
device and recalled later. 15 memory banks are available.
1 Connect a USB memory device to the controller's USB port.
2 Call the menu item [USB Data backup].
3 Select the setting [YES] with the buttons of the lower display and confirm with ENTER. The display indicates
"Press chases button select a file" (select memory bank with number button).
4 Select a memory bank with one of the number buttons 1-15. The display indicates e.g. "FILE:1" and a
progress bar.
● Each memory bank must be stored separately. If the LED of a number button lights, this memory bank has
been stored on the USB memory device before.
● The data will be stored in the folder "DMX_Move_foot_controller" located on the root directory of the USB
memory device. A file with the extension "PRO" will be created for each memory bank. You should not make
any changes to the default folder. Otherwise the controller cannot the reload the data later.
5 After completing the data backup, the device returns to the main menu level.
REGARDING USB MEMORY DEVICES
● This unit supports data carriers with the file system FAT32 and with a capacity up to 32 GB.
● Prior to connecting a USB memory device, call the system settings.
● If a data carrier is not recognized at the first try, turn the controller off and on again
.
