Data import [USB Data load]
1 Connect a USB memory device to the controller's USB port.
● The files to be imported must be stored in the folder "DMX_Move_foot_controller" located on the root directory
of the USB memory device.
2 Call the menu item [USB Data load].
3 Select the setting [YES] with the buttons of the lower display to import data and confirm with ENTER.
● The display indicates " Press chases button select a file" (select file with number button).
● The LED of a number button lights, when data is available on the USB memory device for this memory bank.
4 Select the file to be loaded with the number buttons 1-15.
● The display indicates a progress bar.
5 After successful completion of the data import, the device returns to the main menu level. Repeat the steps 2
and 3 to import further files.
Blackout function [Black-out mode]
It is possible to define whether all control channels react on the BLACKOUT button or only the dimmer control
channels.
Call the menu item [Black-out mode].
1
2 Use the buttons of the lower display to choose between the settings [All channels] and [Only dimmer].
● All channels: All control channels react on the button (i.e. in the blackout state the control channels have the
value zero).
● Only dimmer: Only the dimmer control channels (incl. colors) react on the BLACKOUT button (i.e. in the
blackout state the control channels have the value zero).
3 Confirm your setting with ENTER.
● The display shortly indicates "SAVE OK" and returns to the main menu level.
Naming chases [Setup chases name]
For greater clarity it is possible to name the chases.
1 Call the menu item [Setup chases name].
● The display indicates "Press chases button select a chase" (select file with number button).
2 Select the chased to be named with the number buttons 1-15.
● The display's upper line indicates the memory bank, e.g. "Chase 15" and the lower line indicates the name.
3 Enter the name with the FIXTURE and number buttons 1-15 and confirm with ENTER.
● All LEDs of the controller flash three times to confirm.
4 To delete a name shortly press the DEL button.
5 After your settings, return to the main menu level with ESC.
The internal software (firmware) of the controller can be updated. New versions of the firmware will include new
features, bug fixes and the optimization of current processes. We suggest to always operating the device with the
latest firmware to ensure the highest level of functionality. Check www.eurolite.de from time to time for further
information. The installation procedures may vary slightly from those described in this user manual; please note
the instructions that will be included in the download package.
Follow the steps below to update the firmware:
1 Download the firmware from the internet
2 Create a folder "DMX_Move_foot_controller "on the root directory of a USB memory device.
3 Copy and extract the firmware to the folder on the USB memory device.
4 Connect the USB memory device with the new firmware to the controller's USB port.
5 Turn off the controller.
6 Press and hold the REC button and turn on the controller. After approx. 3 seconds, the display indicates
"PRESS ANY BUTTON TO UPDATE".
7 Release the REC button again.
8 Press any button to start the update procedure.
9 Turn the controller off and on again, as soon as the new firmware has been programmed. The update
procedure is complete and the USB memory device can be removed.
The product is maintenance-free, except for occasional cleaning. You can use a lint-free, slightly dampened cloth
for cleaning. Refer all servicing to qualified personnel.

FIRMWARE UPDATE

www.eurolite.de

CLEANING AND MAINTENANCE

31 • EN
download section of the product.
