Refer to the chart below for an RGBW moving head.
EXAMPLE
Control element
1/D
2/R
3/G
4/B
5/W
6
7
8
9
10
...
14
15/Pan
16/Tilt
Table 6.2 Assignment of DMX channels to the control elements
Caution with spots that have no color mixing, no dimmer channel or no movement. These function channels
are permanently assigned in the console and therefore need to be properly assigned. For example, if a fixture
has no color mixing, channels 2/R, 3/G and 4/B should be set to zero and not be used for other functions.
Otherwise when using color effects you have no satisfying results.
Generally it is recommended to always proceed in the same manner when setting various spots. Consider
which control functions the spots require and work out a fixed scheme. Create a list of the required functions
and sort them according to the standard values of the console and the desired assignments. Record the
respective values of the spots.
Refer to the chart below.
EXAMPLE
Control
Function
element
1/D
Dimmer
2/R
Red
3/G
Green
4/B
Blue
5/W
White
6/A
Color wheel
7/UV
Gobo 1
8
Gobo red
9
Shutter
Focus/Zoom
10
11
Prism
12
Effect
13
Reset
14
Speed
15/Pan
16/Tilt
Table 6.3 Setup example for various spotlights
This chart is simply a suggestion for your assignments. It is important to assign all necessary functions. It is helpful
to assign equal or similar functions to the same encoder. This facilitates clarity and quick programming. Identical
functions, such as color mixing, can be controlled simultaneously for various fixture types.
Function
Dimmer
Red
Green
Blue
White
Shutter/Strobe
Movement speed
Color change
Color change speed
-
-
Horizontal movement
Vertical movement
TMH-75
DMH-32
11-CH mode
16-CH mode
10
5
N1
9
N1
10
N1
11
N1
12
4
7
5
13
6
14
9
4
7
8
8
15
N1
6
11
16
3
3
1
1
2
2
Fixture channel
12
8
9
10
11
6
5
12
13
N1
N1
1
3
Z-Par
ML-56
6-
12-CH mode
CH mode
2
N1
4
1
5
2
6
3
7
4
8
5
9
6
10
N1
3
N1
1
N1
N1
N1
N1
N1
12
N1
11
N1
N1
N1
N1
N1
26 • EN
THA-250F
WF-40
9-
3-CH mode
CH mode
3
6
N1
1
N1
2
N1
3
N1
4
N1
8
N1
N1
N1
N1
2
5
1
N1
N1
9
N1
7
N1
N1
N1
N1
N1
N1
N1
N1
TMH FE
15-CH mode
7
10
11
12
13
14
N1
9
6
N1
N1
8
15
5
1
3
