TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S
POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK • DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This symbol warns user that uninsulated voltage
within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any
kind of contact with any part inside this unit.
This symbol alerts the user that important literature
concerning the operation and maintenance of this
unit has been included. Therefore, it should be read
carefully in order to avoid any problems.
CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with this
equipment, please contact your supplier. For all other cases, please use a power cord that matches the AC voltage of the power outlet and has
been approved by and complies with the safety standard of your particular country.
Plug Type
North America
Plug Shape
Country
U.S.A./Canada
Voltage
* When operating the MultiSync LCD205WNXM/LCD225WNXM/LCD225WNX monitor with its AC 125-240V power supply, use a power supply
cord that matches the power supply voltage of the AC power outlet being used.
NOTE:
This product can only be serviced in the country where it was purchased.
Contents
Power Cord*
User's
Manual
MultiSync LCD monitor
Cable
DVI-D to DVI-D
Management
(LCD225WNX
CD-ROM
Cover
only)
* Type of power cord included will depend on the where the LCD monitor is to be shipped.
Quick Start
Figure A.1
Figure A.2
01_English
WARNING
European Continental
EU (except U.K.)
120*
230
15-pin mini D-SUB
male to 15-pin mini
D-SUB male
USB Cable
(LCD205WNXM/
LCD225WNXM
only)
Audio Cable
Macintosh Cable Adapter (not included)
Figure A.3
English-1
1
Declaration of the Manufacturer
We hereby certify that the color monitors MultiSync LCD205WNXM
(L206T8)/MultiSync LCD225WNXM/LCD225WNX (L226T9) are in
compliance with
Council Directive 73/23/EEC:
and marked with
– EN 60950-1
Council Directive 89/336/EEC:
– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024
U.K.
Chinese
U.K.
China
230
220
Your new NEC MultiSync LCD monitor box* should contain the
following:
•
MultiSync LCD monitor with tilt base
•
Audio Cable
•
Power Cord
•
Video Signal Cable (15-pin mini D-SUB male to 15-pin mini
D-SUB male)
•
Video Signal Cable (DVI-D to DVI-D) (LCD225WNX only)
•
USB Cable (LCD205WNXM/LCD225WNXM only)
•
User's Manual
•
Cable Management Cover
•
CD-ROM
Remember to save your original box and packing material to transport or ship
*
the monitor.
To attach the MultiSync LCD monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. For the PC or MAC with DVI digital output: Connect the DVI-D
signal cable (not included for the U.S. and China) to the connector of
the display card in your system (Figure A.1). Tighten all screws.
For the PC with Analog output: Connect the 15-pin mini D-SUB
signal cable to the connector of the display card in your system
(Figure A.2). Tighten all screws.
For the MAC: Connect the MultiSync Macintosh cable adapter
(not included) to the computer. Attach the 15-pin mini D-SUB signal
cable to the MultiSync Macintosh cable adapter (Figure A.3).
Tighten all screws.
NOTE:
Some Macintosh systems do not require a Macintosh cable
adapter.
9/10/07, 6:42 PM
NEC Display Solutions, Ltd.
4-13-23, Shibaura,
Minato-Ku
Tokyo 108-0023, Japan
Japanese
Japan
100
